Application Field:
Inverter; inverter (inverter welding machine, photovoltaic inverter) converter; switching power supply; EMC filter; wind power; household appliances;
Performance characteristics：
l High saturation magnetic induction;
l Excellent wide frequency characteristics;
l Extensive permeability adjustment range;
l Better anti - unbalanced current capability;
l Excellent temperature stability (high temperature);
l Low loss.
Material properties：
Saturation magnetic induction Bs（T） | 1.2 |
Coercivity Hc （A/m） | <2 |
Curie temperature Tc（℃） | 570 |
Crystallization temperature Tx（℃） | 500 |
Lamination factor | >0.75 |
Working temperature℃ | -40～130 |
Initial permeability μi（Br≈0.8T） | 18×104 |
Initial permeability μi（Br≈0.4T） | 10×104 |
Initial permeability μi（Br≈0.1T） | 3×104 |
loss P（20kHz，0.5T），（W/kg） | <20 |
